Products
MWTS02 Miniature Ultrasonic Wind Speed and Direction Meteorological Sensor
Miniature Ultrasonic Wind Speed and Direction Meteorological Sensor: High Precision, Strong Stability, Applied in Meteorological Environment Monitoring
place of origin： Beijing, China
warranty：2 years
customized support：OEM
brand name：Tsingsense
model number：MWTS02
Operating Voltage：9V~30VDC
Humidity Range：0-100%RH
Resolution：Professional level
Output interface：RS485(RS232 can be selected)
Product Description
TS MWTS02 ultrasonic wind speed and wind direction sensor is a professional-grade miniature sensor independently developed by our company to measure a variety of meteorological elements. It can simultaneously measure wind direction, wind speed and other meteorological elements. It has the advantages of high precision, fast response time, strong anti-interference ability and serial output. Users can directly measure through PC or external instruments.
Features
- Open system protocol
- Ultra-low power design (less than 0.2W)
- Maintenance-free system design, high accuracy
- Standard RS485 output (RS232 optional)
- Industrial-grade protective shell ensures long-term field use
- Optional built-in electronic compass, GPRS, GPS, etc.
Technical Parameters
Factor | Measuring range | Resolution | Accuracy | Measure principle |
| Wind direction | 0~360° | 1° | ±3° | Ultrasonic |
| Wind speed | 0~55m/s | 0.1m/s | ±0.3m/s or 3% | Ultrasonic |
Optional configuration function(Built-in sensor ):GPRS-a01, WiFi-a02, Ethernet-a03, Electronic compass-b01, GPS-b02, Heating, Battery-d01. | ||||
Packing list
Sensor 1 set
3.5m cable 1 line
Instruction 1 copy
Certificate/warranty 1 copy
FAQ for MWTS02
Q:Do you supply tripod and solar panels?
A:Yes, we can supply it, but this is optional.
Q:Can we choose the required sensor for the weather station?
A:Yes, you should tell us what sensors you need before placing the order, and then we will quote according to your request.
Q:What is the way of transmission mode?
A:Communication interface adopts RS485,(RS232 can be selected)
