WTS201 Atmospheric Temperature and Humidity weather Sensorfor
High-Precision WTS201 Atmospheric Temperature and Humidity Meteorological Sensor for Environmental Monitoring - Ideal for Meteorology and Environmental Protection
Product Description
WTS201 two parameter integrated meteorological sensor is a professional sensor developed by our company to measure various meteorological elements.It can simultaneously measure two meteorological parameters: atmospheric temperature and atmospheric humidity.It has the advantages of high accuracy, fast response time, strong anti-interference ability, serial port output and so on.Users can measure directly through PC or external instruments.
Features
● Integrated design of multiple sensors,(No need for a receiver )
● Design of maintenance free system,(Simple installation)
● Open system protocol
● Communication interface adopts RS485,(RS232 can be selected)
● Low-power design
● Industrial protective shell,( Ensure long-term outdoor use)
● Optional built-in electronic compass, GPRS, GPS, etc.
Technical Parameters
Factor | Measuring range | Resolution | Accuracy | Measurement principle |
Air temperature | -40℃~+85℃ | 0.1℃ | ±0.3℃ | Thermistor |
Air humidity | 0~100%Rh | 1%Rh | ±2%Rh | Capacitance |
Optional configuration function(Built-in sensor ):GPRS-a01, WiFi-a02, Ethernet-a03,Electronic compass-b01, GPS-b02, Heating(48W)-c01, Heating(100W)-c02, Battery-d01. | ||||
Packing list
sensor 1 set
3.5m cable 1 line
instruction 1 copy
certificate/warranty 1 copy
packing list 1 copy
FAQ for WTS201 sensor
Q:Do you supply tripod and solar panels?
A:Yes, we can supply it, but this is optional.
Q:Can we choose the required sensor for the weather station?
A:Yes, you should tell us what sensors you need before placing the order, and then we will quote according to your request.
Q:What is the way of transmission mode?
A:Communication interface adopts RS485,(RS232 can be selected)
